Ford Ranger Diesel (from 2023) — pre-cut PPF pattern

Ford Ranger Diesel 2023 precut PPF pattern – watermarked preview from the cutting software — Preview as shown in AutoVectors Studio Pro. Watermarked, not to scale, not a cut file.

Make: Ford
Model: Ranger Diesel
Family: Ranger
Model year: from 2023
Shelf: Cars — paint protection film
Size: medium kit
Template id: ford-ranger-diesel-2023-ppf-5a1624 — quote this id when you ask

A paint protection film pattern for the Ford Ranger Diesel, model year 2023 onward: a medium kit, drawn as one template in the AutoVectors Studio Pro vehicle library. Studio Pro is PPF cutting software: it opens the template at your roll width, nests the pieces and sends each sheet straight to the plotter. The Ford Ranger family in the library also has PPF patterns from 2023, 2024 and 2025, listed on the Ford Ranger page.

More Ford Ranger kits

All Ford Ranger templates →

More from Ford

Bronco U725 Raptorfrom 2023 · SUV

AutoVectors Studio Pro – PPF cutting software for Windows

AutoVectors Studio Pro is PPF cutting software for Windows — our own pre-cut software for paint protection film installers, with this library of precut PPF patterns built in. Pick a template, set your roll width, let Autonest nest the pieces, and send the sheet straight to your cutting plotter — no file juggling, no export step. Templates are licensed, not sold as files: they open only inside Studio Pro and cannot be downloaded, saved to your PC or exported to SVG, DXF, PLT or any other format. The pictures on these pages are watermarked previews — not to scale and not cut files. Studio Pro is a subscription for vetted shops and is not a public download: ask for it and we send a personal download link.
